ภาพรวม
Key Features: - Excellent strength-to-weight ratio - Superior corrosion resistance (especially marine atmosphere) - Outstanding machinability and weldability - Stress-relieved for improved dimensional stability - Good formability and anodizing response - Pre-stretched to minimize warping during machining High-quality 6061-T651 aluminum plate with superior strength, corrosion resistance & machinability. ASTM B209 certified. Ideal for aerospace, marine & industrial applications.
คำอธิบาย (อังกฤษ)
6061-T651 aerospace aluminum is a high-strength material that is commonly used in the aerospace industry for its toughness, excellent weldability, and good corrosion resistance. It has a high strength-to-weight ratio, making it a popular choice for aircraft, spacecraft, and other vehicles where weight is a critical factor.
ช่วงขนาด
- thickness:1-500mm
ข้อกำหนดเกรด
| ระบบ | ค่า |
|---|---|
| thickness | 1-500mm |
| width | 50-2500mm |
| length | 50-18000mm |
องค์ประกอบทางเคมี
| ธาตุ | ค่า |
|---|---|
| Al | 95.8-98.6 |
| Mg | 0.8-1.2 |
| Si | 0.4-0.8 |
| Fe | 0.7 |
| Cu | 0.15-0.4 |
| Cr | 0.04-0.35 |
| Zn | 0.25 |
| Ti | 0.15 |
| Mn | 0.15 |
คุณสมบัติเชิงกล
| productCenter.property | ค่า |
|---|---|
| Density | 2.70 g/cm³ (0.0975 lb/in³) |
คุณสมบัติทางกายภาพ
| คุณสมบัติ | หน่วย | ค่า |
|---|---|---|
| Tensile Strength | - | ≥ 290 |
| Yield Strength | - | ≥ 240 |
| Elongation | - | ≥ 10 |
การใช้งาน
- Aircraft structures
- Wing skins and spars
- Fuselage frames
- Helicopter rotor hubs
- Missile components
- Structural components
