Overview
Hastelloy C-22 (UNS N06022 / DIN 2.4602) machined fittings for capsule filler jig and feeding wheel assemblies — the corrosion-proof upgrade for original stainless steel wear parts. As a specialized C22 jig fittings supplier for pharmaceutical tooling, Vertex Alloy CNC-machines jig bodies, guide bushings, feeding wheel inserts, segments and wear rings per your drawing or sample (reverse engineering available) to ±0.01 mm, with polished contact faces, 100% dimensional inspection, full heat-number traceability and EN 10204 3.1 certificates. C-22's outstanding pitting resistance (PREN ≈ 66, better than C-276) keeps fittings running where 316L and 17-4PH parts corrode, gall and seize. MOQ from 1 piece; all major encapsulator brands supported. Send your drawings or samples for a fast quotation.
Description (English)
Hastelloy C-22 (UNS N06022, DIN 2.4602) machined fittings and wear parts for capsule filling machine jig assemblies and feeding wheels. When corrosive or abrasive formulations attack original stainless steel jig components and feeding wheel parts — causing corrosion, galling, seizure and downtime — C-22 replacement fittings (PREN ≈ 66, superior to C-276) extend service life several times over and never contaminate the product. Vertex Alloy CNC-machines jig bodies, guide bushings, feeding wheel inserts, segments, wear rings and locating pins per your drawing or sample (reverse engineering from used OEM parts available), to ±0.01 mm with polished contact faces. Every order ships with 100% dimensional inspection reports, full heat-number traceability and EN 10204 3.1 certificates. MOQ from 1 piece; compatible with Bosch GKF, IMA, MG2, Harro Höfliger, Sejong and all major encapsulators.
Applications
C22 Fittings for Jig Feeding Wheel Supplier | Hastelloy C-22 N06022 Machined Parts is supplied for demanding applications such as Pharmaceutical — Encapsulation, Pharmaceutical — Tableting, Chemical Processing, Flue Gas Desulfurization, Marine, and Nuclear. These application areas rely on a carefully specified metal product that can be selected by grade, form, dimensions, and service requirements rather than by a generic material description. The listed applications provide practical context for engineers and purchasing teams reviewing this product: they indicate where corrosion resistance, strength, fabrication performance, or dimensional consistency may matter. Final suitability depends on the operating environment, design code, temperature, media, joining method, and applicable inspection requirements. Buyers can use the application information together with the grade and property data below to request a technically appropriate specification, finish, tolerance, and quantity from Vertex Alloy.
Key Mechanical & Physical Properties
C22 Fittings for Jig Feeding Wheel Supplier | Hastelloy C-22 N06022 Machined Parts is described using the available technical records rather than an assumed specification. The supplied data includes mechanical data including key 5f03a222fc13, type mech_item, property Tensile Strength, value ≥ 690 MPa, mechanical data including key e148c093ed0e, type mech_item, property Yield Strength, value ≥ 283 MPa, mechanical data including key f3893eacfe7e, type mech_item, property Elongation, value ≥ 45 %, mechanical data including key c19f41441c38, type mech_item, property Hardness, value ≈ 87 HRB (190 HB), physical data including key 881f029848cf, type phys_item, property Density, value 8.69 g/cm³, physical data including key 88a6ad1862e5, type phys_item, property Melting Range, value 1351 – 1387 °C, physical data including key 25bd2bbfa752, type phys_item, property Thermal Conductivity, value 10.1 W/(m·K), physical data including key 6591ccd20078, type phys_item, property Electrical Resistivity, value 1.28 μΩ·m, physical data including key 05891570c757, type phys_item, property Elastic Modulus, value 205 GPa, physical data including key 12e6ede41732, type phys_item, property Thermal Expansion (20–100 °C), value 12.4 × 10⁻⁶ /K, physical data including key 357760dd988a, type phys_item, property Magnetic, value No, composition data including key 13f0b998343e, type composition_item, element Nickel (Ni), value Balance (≥ 56), composition data including key e03ab26734a0, type composition_item, element Chromium (Cr), value 20.0 – 22.5, composition data including key 7de0c6c1b836, type composition_item, element Molybdenum (Mo), value 12.5 – 14.5, composition data including key 0bb516b73ee3, type composition_item, element Tungsten (W), value 2.5 – 3.5, composition data including key 500b9db23172, type composition_item, element Iron (Fe), value 2.0 – 6.0, composition data including key d0d8d95f880a, type composition_item, element Cobalt (Co), value ≤ 2.5, composition data including key 9b6f42432d85, type composition_item, element Carbon (C), value ≤ 0.015, composition data including key 859066f99d1a, type composition_item, element Manganese (Mn), value ≤ 0.50, composition data including key c102a0935ac6, type composition_item, element Silicon (Si), value ≤ 0.08, composition data including key 3182bf4e5844, type composition_item, element Vanadium (V), value ≤ 0.35, composition data including key 7e2b355acc33, type composition_item, element Phosphorus (P), value ≤ 0.02, and composition data including key fce361548c2d, type composition_item, element Sulfur (S), value ≤ 0.02. Keeping these values visible helps a technical buyer compare the product with a drawing, purchase specification, or applicable standard before requesting a quotation. Mechanical values can guide early checks for strength and forming requirements, while physical values and composition details help with material identification, process planning, and service-environment review. Values should be confirmed against the latest mill certificate, heat or lot documentation, product condition, test method, and governing standard before production use. Vertex Alloy can review the required performance range and clarify which supplied values apply to the requested size and delivery condition.
Available Sizes & Forms
C22 Fittings for Jig Feeding Wheel Supplier | Hastelloy C-22 N06022 Machined Parts is listed in others form with size information including Part Size (max envelope):Up to 400 mm diameter × 500 mm length, Bar Stock Diameter:2 – 120 mm (ASTM B574), Tolerance:Up to ± 0.01 mm, Surface Finish: Ra 0.4 – 1.6, and Order Quantity:1 piece to series production. The size range is intended to help buyers screen availability and prepare an enquiry; it is not a substitute for a confirmed production schedule or tolerance agreement. When requesting this product, include thickness or diameter, width or length, cut-to-size needs, edge condition, surface finish, straightness, tolerance, quantity, and preferred packing. Dimensions may vary with grade, processing route, minimum order quantity, and mill capacity. Sharing the complete requirement allows Vertex Alloy to check whether the requested size can be supplied directly, cut from stock, or produced to order. The final commercial confirmation should state the agreed form, dimensions, tolerances, condition, inspection documents, and delivery terms.
Grade Compliance
C22 Fittings for Jig Feeding Wheel Supplier | Hastelloy C-22 N06022 Machined Parts carries the recorded grade references UNS (USA) N06022, DIN / EN (Germany/EU) 2.4602 / NiCr21Mo14W, Haynes Trademark HASTELLOY® C-22®, GB (China) NS 338 / 00Cr22Ni60Mo13W3, and Common Names Alloy 22. These references give engineering and procurement teams a starting point for checking material identity, equivalent designations, and documentation requirements. A grade reference should always be read together with its applicable standard, product form, dimensional range, delivery condition, heat treatment, testing requirements, and revision level. Equivalent designations are not automatically interchangeable in every service, so the governing project specification remains controlling. Before order placement, confirm the required standard and certificate format, including chemical, mechanical, visual, dimensional, and any special testing requirements. Vertex Alloy can help compare the requested designation with the available product record and identify details that need confirmation from the producing mill.
Size Range
- Part Size (max envelope):Up to 400 mm diameter × 500 mm length
- Bar Stock Diameter:2 – 120 mm (ASTM B574)
- Tolerance:Up to ± 0.01 mm
- Surface Finish: Ra 0.4 – 1.6
- Order Quantity:1 piece to series production
Grade Specification
| System | Value |
|---|---|
| UNS (USA) | N06022 |
| DIN / EN (Germany/EU) | 2.4602 / NiCr21Mo14W |
| Haynes Trademark | HASTELLOY® C-22® |
| GB (China) | NS 338 / 00Cr22Ni60Mo13W3 |
| Common Names | Alloy 22 |
Chemical Composition
| Element | Value |
|---|---|
| Nickel (Ni) | Balance (≥ 56) |
| Chromium (Cr) | 20.0 – 22.5 |
| Molybdenum (Mo) | 12.5 – 14.5 |
| Tungsten (W) | 2.5 – 3.5 |
| Iron (Fe) | 2.0 – 6.0 |
| Cobalt (Co) | ≤ 2.5 |
| Carbon (C) | ≤ 0.015 |
| Manganese (Mn) | ≤ 0.50 |
| Silicon (Si) | ≤ 0.08 |
| Vanadium (V) | ≤ 0.35 |
| Phosphorus (P) | ≤ 0.02 |
| Sulfur (S) | ≤ 0.02 |
Mechanical Properties
| productCenter.property | Value |
|---|---|
| Tensile Strength | ≥ 690 MPa |
| Yield Strength | ≥ 283 MPa |
| Elongation | ≥ 45 % |
| Hardness | ≈ 87 HRB (190 HB) |
Physical Properties
| Property | Unit | Value |
|---|---|---|
| Density | g/cm³ | 8.69 g/cm³ |
| Melting Range | °C | 1351 – 1387 °C |
| Thermal Conductivity | W/m·K | 10.1 W/(m·K) |
| Electrical Resistivity | μΩ·cm | 1.28 μΩ·m |
| Elastic Modulus | GPa | 205 GPa |
| Thermal Expansion (20–100 °C) | ×10⁻⁶/K | 12.4 × 10⁻⁶ /K |
| Magnetic | - | No |
Applications
- Pharmaceutical — Encapsulation
- Pharmaceutical — Tableting
- Chemical Processing
- Flue Gas Desulfurization
- Marine
- Nuclear
